An insulated hot line looks like one object; corrosion sees four layers, each with a job, and the failures land wherever a layer was skipped. Assembling the stack correctly is corrosion under insulation prevention in its practical form, applying the NACE SP0198 logic from our earlier CUI guides.
Layer one: the prepared steel
Everything rests on ISO 8501-1 Sa 2.5 with verified salt limits, exactly as immersion service demands. Under insulation the coating will spend years wet and warm; preparation shortcuts surface here first.
Layer two: the CUI rated coating
Chosen by temperature band per our selection shortlist: qualified epoxies and novolacs to their ceilings, inert multipolymeric matrix and qualified high temperature systems above, always specified for the cycling range, not the nameplate temperature. This is the actual corrosion barrier; the insulation system above it is weather protection that will eventually leak.
Layer three: the insulation, chosen to shed suspicion
Insulation choice affects corrosion: water absorbent materials hold leakage against the coating, and some contribute leachable chlorides. Water repellent grades and chloride limited certifications, with drainage conscious detailing at supports and low points, materially lengthen the system's life.
Layer four: cladding and its details
Metal jacketing sheds weather when lapped correctly, sealed at terminations and penetrations, and maintained. Most CUI inspection finds trace to identifiable cladding defects: crushed jackets at walkway height, missing end caps, upward facing seams. A cladding walkdown twice a year is the cheapest CUI programme component that exists.
The system truth
Each layer assumes the next will fail occasionally; the stack works when every layer is present and honest. Skip one and the calendar to the first CUI finding shortens by years.
